220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving

220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving

Large Image :  220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving

Product Details:
Place of Origin: Henan, China
Brand Name: Be Focus
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $478.00/sets 1-4 sets
Packaging Details: Wooden box packaging
Supply Ability: 1000 Set/Sets per Month
Contact Now

220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving

Description
Applicable Industries: Building Material Shops, Manufacturing Plant, Farms, Retail, Construction Works , Energy & Mining Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Not Available
Marketing Type: Hot Product Warranty Of Core Components: 1 Year
Core Components: PLC, Engine, Gearbox, Motor Condition: New
Voltage: 220v/380v Power: 3KW
Weight: 75 Kg Dimension(L*W*H): 890mm*550mm*990mm
Warranty: 1 Year UNIQUE SELLING POINT: Energy Saving
Product Name: Tamping Rammer Machine Keyword: Tamping Rammer
Application: Road Construction Engine Type: Electric/Gasoline/Diesel
Color: Blue/Yellow/Red/Customized Jumping Height: 45-75mm
Impact Force: 16-22KN Forward Speed: 9-13m/min
Tamping Depth: 35cm Port: QingDao/ShangHai/TianJin/Dalian/Shenzhen

Product Description
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 0
Tamping rammer has a better effect on tamping viscous soil. Tamping rammer is suitable for construction in buildings, floors,courtyards, subgrades, bridge piles, trenches, fields, narrow sites and other environments. It can be competent for construction tasks that cannot be completed by large and medium-sized machinery. The product has the characteristics of compact structure,large tamping force, flexible operation, safe use, practicality, etc.
Specification
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 1
Metric
Model
HCD-100
HCD-110
HCD-125
HCD-130
Weight(kg)
82
85
87
90
Host length(mm)
760
890
810
900
Host width(mm)
410
550
430
550
Host height(mm)
970
990
990
1000
Shoe size(mm)
L320*W280
L320*W280
L320*W280
L320*W280
Impact force(kn)
16
18
20
22
Jumping height(mm)
45-60
45-65
45-70
45-75
Forward speed(m/min)
9-13
9-13
9-13
9-13
Engine Type
Gasoline/diesel/electric
Gasoline/diesel/electric
Gasoline/diesel/electric
Gasoline/diesel/electric
Tamping depth
35 cm
35 cm
35 cm
35 cm
Imperial
Model
HCD-100
HCD-110
HCD-125
HCD-130
Weight
180.78 ib
187.39 ib
191.80 ib
198.42 ib
Host length
29.92''
35.04''
31.89''
35.43''
Host width
16.14''
21.65''
16.93''
21.65''
Host height
38.19''
38.98''
38.98''
39.37''
Shoe size
12.60''*11.02''
12.60''*11.02''
12.60''*11.02''
12.60''*11.02''
Impact force
16 kn
18 kn
20 kn
22 kn
Jumping height
Gasoline/diesel/electric
Gasoline/diesel/electric
Gasoline/diesel/electric
Gasoline/diesel/electric
Tamping depth
13.78''
13.78''
13.78''
13.78''
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 2
Product details
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 3
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 4
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 5
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 6

Product Advantages

1. The stroke is adjustable and can compact different soils and asphalt pavements.
2. The large enclosed air filter system is easy to clean and the engine is not easy to damage.
3. The special muffler cover can reduce the noise generated by the engine and the bottom plate to the operator.
4. The shock-absorbing guide handle can reduce the fatigue of the operator.
5. The bottom plate made of ductile iron has a longer service life.
6. Fully airtight, splash lubrication impact system to ensure lubrication of parts.


Be focus Gasoline Tamping Rammer Tamping Rammer Parts Clutch Rail Road Tamping Machine
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 7
Packaging & Delivery
220v/380v Vibratory Tamping Rammer For Frog Tamping With Energy Saving 8
We adopt wooden and iron box to pack machines, better guarantee the safety and quality of products.And we adopt multiple port, multiple exit point. Such as Shanghai, Qingdao, Guangdong and other regions. Product transportation will be faster and more convenient.
