Product Details:
Place of Origin: Henan, China
Certification: CE,ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $2,280.00/sets 1-4 sets

Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally

Description
Applicable Industries: Building Material Shops, Machinery Repair Shops, Retail, Construction Works  Showroom Location: None
Condition: New Power Type: Diesel/Electric
Weight: 400 Kg Dimension(L*W*H): 1800*594*1250mm
Warranty: 1 Year UNIQUE SELLING POINT: High Load Moment
Max. Vertical Conveying Distance: 10-180M Max. Horizontal Conveying Distance: 20-250M
Productivity: 8M³/H Machinery Test Report: Provided
Video Outgoing-inspection: Provided Marketing Type: New Product 2022
Warranty Of Core Components: 1 Year Core Components: Motor, Pump, Gearbox, Engine
Product Name: Mini Diesel/Electric Concrete Pump Keword: Small Concrete Pump
Power: 45KW Model: XK15/XK30/XK45
Max Aggregate Size: 20 Mm SIZE: 1800*594*1250mm
Capacity: 8-14 M*3/h Application: Roads, Railways, Tall Buildings, Bridges, Tunnels


Product Description
Product Description
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 0
Mini concrete delivery pumps are widely used in compacting grouting, chemical grouting, foundation reinforcement, waterproof and plugging, soil anchor rod construction, rotary spray construction, drilling construction, tree root pile, double overflow grouting, thunderbolt grouting, etc.
Tatooine Mini Secondary Structure Concrete Pump Truck

Specification
Specification
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 1
Metric dimensions specifications

Model
XK-15
XK-20
XK-30
XK-37
Weight (KG)
600
1000
1300
1400
Aggregate size (MM)
<20
<20
<30
<30
Conveying pipe diameter (MM)
Φ80
Φ80
Φ100/Φ80
Φ100/Φ80
Dimension (M)
1.8*0.7*1.1
2.7*1.1*1.2
3.0*1.2*1.3
3.0*1.2*1.3
Conveying height (M)
15-20
25-40
40-80
50-100
Conveying distance (M)
40-50
50-80
80-160
100-200
Power (KW)
15
22
30
37
Theoretical efficiency (M³/H)
6-8
8-12
10-15
15-20
Metric dimensions specifications

Model
XK-45
XK-50
ZS-45 Diesel
ZS-50Diesel
Weight (KG)
2300
2500
2200
2980
Aggregate size (MM)
<30
<40
<30
<40
Conveying pipe diameter (MM)
Φ100/Φ80
Φ100/Φ80
Φ100/Φ80
Φ100/Φ120
Dimension (M)
4.7*1.5*1.6
4.2*1.5*1.6
3.6*1.2*1.5
4.2*1.4*1.5
Conveying height (M)
80-150
100-180
80-120
100-150
Conveying distance (M)
180-250
200-300
150-250
200-300
Power (KW)
45
55
Diesel 4108 72KW
Diesel 6105 130KW
Theoretical efficiency (M³/H)
20-25
30-40
18-25
30-40

Product Details
Product Details
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 2
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 3
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 4
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 5
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 6
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 7
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 8

Product advantage

1. The power system, hydraulic system and pumping system are reasonably matched to effectively exert the power of the motor and improve the material absorption.
2. The configuration is more optimized, and the original imported hydraulic parts and electrical components are adopted to greatly improve the reliability of the equipment. The unique distribution oil circuit buffer technology ensures that the S tube swings in place and prolongs the service life of the S tube.
3. The application of high and low voltage switching simplifies the operation mode.

4. The lubrication system adopts a forced filtration and pre-pressure dual-pump energy-saving automatic centralized oil supply system, which provides sufficient oil supply, better lubrication effect, and reduces consumption by more than 50% compared with ordinary continuous oil injection.
5. The application of new wear-resistant materials and welding technology improves the service life of commonly used wearing parts.
6.The hydraulic system has proprietary hydraulic buffering technology, which makes the system have less reversing impact and less heating.
Tatooine Mini Secondary Structure Concrete Pump Truck
Related Accessories Display of Concrete Pump
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 9
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 10
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 11
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 12
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 13
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 14



Packing & Delivery
Packing & Delivery
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 15
We adopt wooden and iron box to pack machines, better guarantee the safety and quality of products.And we adopt multiple port, multiple exit point. Such as Shanghai, Qingdao, Guangdong and other regions. Product transportation will be faster and more convenient

Company Profile
Company Profile
Henan Tatooine Mechanical Equipment Co.,Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system. Henan Tatooine Mechanical Equipment Co.,Ltd was established in the nineties of twenty century and is one of the earliest professional manufacturers in the field of construction machinery In the spirit of professionalism and excellence,we have gradually developed into a large factory with a history of 30 years. The equipment we provid includes steel bar bending machine,steel bar cutting machine steel bar straightening machine concrete laser screed,concrete cutting machinepower plastering machinerollerconcrete screedconcrete mixer and so on. Has more than 100 engineering and technical experience. Construction machinery we can meet your different orders. In addition, our professional R &:D team will provide you with the most convenient service, Since your order, we can provide the best products and service for you.
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 16
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 17
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 18
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 19
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 20
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 21

Certifications
Certifications
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 22
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 23
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 24

Customer Photos
Customer Photos
Hydraulic System Concrete Pump for Conveying up to 180M Vertically and 250M Horizontally 25

FAQ
FAQ
1. Who are we? We are based in Henan, China, start from 2005,sell to Domestic Market(40.00%),North America(15.00%),Southeast Asia(10.00%),Africa(10.00%),South America(5.00%),Oceania(5.00%),Western Europe(5.00%),Eastern Europe(3.00%),Mid East(2.00%),Eastern Asia(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 21-50 people in our office. 2. How can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment; 3.What can you buy from us? Concrete Mixer,Concrete Pump,Concrete Road Paver,Steel Bar Straightening and Cutting Machine,Steel Bar Bending Machine 4. Why should you buy from us not from other suppliers? Henan Tatooine Machinery Manufacturing Co., Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system. 5. What services can we provide? Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES; Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF; Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow; Language:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,
