Product Details:
|
| Applicable Industries: | Building Material Shops, Construction Works , Energy & Mining | Showroom Location: | None |
|---|---|---|---|
| Condition: | New | Power Type: | Electric |
| Weight: | 90 Kg | Dimension(L*W*H): | 1030*300*300 |
| Warranty: | 1 Year | UNIQUE SELLING POINT: | High Operating Efficiency |
| Max. Vertical Conveying Distance: | 15M | Max. Horizontal Conveying Distance: | 100M |
| Productivity: | 85M³/H | Machinery Test Report: | Not Available |
| Video Outgoing-inspection: | Provided | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, Bearing, Pump, Other |
|
Model number
|
Power(KW)
|
Flow(m³)
|
Pressure(mpa)
|
Dimension(m)
|
|
YLRG25
|
1.5
|
2
|
1
|
0.9*0.3*0.3
|
|
YLRG32
|
2.2-3
|
3
|
1
|
1.0*0.4*0.4
|
|
YLRG40
|
4
|
4
|
1.5
|
1.1*0.5*0.48
|
|
YLRG50
|
5.5
|
5
|
2
|
1.2*0.7*0.6
|
|
YLRG65
|
7.5
|
10
|
2
|
1.4*0.85*0.8
|
|
YLRG75
|
11
|
20
|
2
|
1.5*1.0*0.9
|
|
YLRG100
|
15
|
50
|
1.5
|
1.7*1.3*1.1
|
|
Model number
|
Weight(kg)
|
Inner diameter of pipe(mm)
|
Pipe outside diameter(mm)
|
Working ability(m)
|
|
YLRG25
|
60
|
25
|
49
|
vertical:10 level:80
|
|
YLRG32
|
90
|
32
|
60
|
vertical:15 level:100
|
|
YLRG40
|
120
|
38
|
66
|
vertical:15 level:100
|
|
YLRG50
|
200
|
50
|
84
|
vertical:20 level:120
|
|
YLRG65
|
350
|
65
|
116
|
vertical:25 level:150
|
|
YLRG75
|
480
|
75
|
100
|
vertical:20 level:150
|
|
YLRG100
|
980
|
100
|
148
|
vertical:12 level:150
|
