Product Details:
|
| Type: | Straightener & Cutter | Condition: | New |
|---|---|---|---|
| Use: | Rebar / Steel Bar Straightener & Cutter | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Hot Product 2024 |
| Warranty Of Core Components: | 1 Year | Core Components: | PLC, Engine, Motor |
| Voltage: | 220v/380v/440v | Dimension(L*W*H): | 250*76*115 |
| Warranty: | 1 Year | Key Selling Points: | Easy To Operate |
| Applicable Industries: | Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Home Use, Retail, Construction Works , Other | Showroom Location: | Spain, Colombia, Algeria, Kyrgyzstan |
| Weight (KG): | 650 | Product Name: | Wire Straightening Cutting Machine |
| Straightening Speed: | 35-60 Meters/minute | Color: | Black, Yellow, Red Or Customized |
| Motor Power: | 7.5-16kw | Straightening Diameter: | 4-14mm |
| Control System: | Automatic | Application: | Industrial Metal Cutting And Straightening |
| Feature: | Accuracy | After-sales Service Provided: | Online Video Technical Support |
Metric dimensions specifications | ||||||||||
Model | YGT4-12 | YGT 5-14 | YGT6-14 | GT2-5 | YGT6-10 | |||||
Motor power | 7.5 KW | 11+5.5 KW | 7.5+4+4 kw | 9 kw | 4+4 KW | |||||
Straightening rate | 35-50 m/min | 0-70 m/min | 45-65 m/min | 35-50 m/min | 35-50 m/min | |||||
Weight | 260 kg | 900 KG | 800kg | 300 kg | 360 kg | |||||
Straightened round bar | 6-12 mm | 6-14 mm | 6-14 mm | 2-5 mm | 6-10 mm | |||||
Straightened rebar | 6-10 mm | 6-12 mm | 6-12 mm | 2-5 mm | 6-8 mm | |||||
Host length | 130 cm | 250 cm | 282 cm | 155 cm | 178 cm | |||||
Host width | 65 cm | 76 cm | 72 cm | 96 cm | 84 cm | |||||
Host height | 95 cm | 115 cm | 108 cm | 65 cm | 66 cm | |||||
