Product Details:
|
| Applicable Industries: | Building Material Shops, Machinery Repair Shops, Retail, Construction Works , Other | Showroom Location: | None |
|---|---|---|---|
| Condition: | New | Type: | Vibratory Roller |
| Travel Speed: | 0~4km/h | Grade Ability: | 30% |
| Power: | 15 KW, 7.5 KW | Dimension(L*W*H): | 2100*1500*950mm |
| Weight: | 0.8 TON | Warranty: | 1 Year |
| Hydraulic Pump Brand: | / | Hydraulic Valve Brand: | / |
| Engine Brand: | CHANGFA | UNIQUE SELLING POINT: | High Operating Efficiency |
| Drum Diameter: | 800mm | Drum: | Double Drum Roller |
| Exciting Force: | 32KN | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | New Product 2024 |
| Warranty Of Core Components: | 1 Year | Core Components: | Pressure Vessel, Motor, Bearing, Engine, Gearbox |
| Product Name: | Road Roller | Keywords: | Double Drum Vibratory Road Roller |
| Drive Mode: | Hydraulic Drive Unit | Vibrate Frequency: | 70HZ |
| Water Tank Capacity: | 60L | Fuel Tank Capacity: | 19L |
| Starting Mode: | Electric Starting | Wheel Size: | 740*530mm |
| Color: | Customer's Demands | After-sales Service Provided: | Video Technical Support |
Metric Dimensions Specifications | ||||||||
Model | FVR700S | FVR600D | FVR850 | FVR880 | ||||
Weight(kg) | 500 | 550 | 750 | 1000 | ||||
Power(kw) | 5.5/4.0HP/KW | 5.5/4.0HP/KW | 9/6.7HP/KW | 9/6.7HP/KW | ||||
Engine | Diesel changfa 178FE | Diesel changfa 178FA | Diesel changfa 180FA | Diesel changfa 180FA | ||||
Walking speed(km/h) | 0-4 | 0-4 | 0-4 | 0-5 | ||||
Roller size(mm) | 560*700 | 600*426 | 700*560 | 740*530 | ||||
Capacity of water tank(L) | 15 | 35 | 15 | 60 | ||||
Drive model | Hydraulic drive | |||||||
Walking model | Forward/Back | |||||||
Capacity of fuel tank(L) | 3.6 | 6 | 3.6 | 19 | ||||
Package size (mm) | 1000*1000*1200 | 1350*940*1220 | 2000*900*1400 | 2100*1500*950 | ||||
