Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity

Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity

Large Image :  Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity

Product Details:
Place of Origin: Henan, China
Brand Name: Be-Focus
Model Number: C90T, FCP200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $268.00/sets 1-4 sets
Contact Now

Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity

Description
Applicable Industries: Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Home Use, Retail, Construction Works , Energy & Mining, Other Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product 2024 Warranty Of Core Components: 1 Year
Core Components: PLC, Engine, Motor, Gear Condition: New
Application: Ground Compaction Power: 9.6KW
Dimension(L*W*H): 965*600*1370mm Weight: 150 Kg
Warranty: 1 Year UNIQUE SELLING POINT: High Operating Efficiency
Product Name: Vibratory Plate Compactor Engine: Gasoline/Diesel/Electric
Engine Type: Air-cooled 4-cycle Gasoline System: Mechanical Control
Speed: 22m/ Min Plate Size Mm(in): 600*890mm
Max Speed: 3600rpm Fuel Tank: 5.5L
Vibrating Frequency: 2800-5500vpn Working Area: 500*520 Mm

Product Description
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 0
Plate compactor is suitable for tamping the engineering foundation, curb and asphalt pavement when building roads, streets, buildings, canals and bridges in highways, municipal administration, construction, water conservancy and other areas. In a narrow working environment, it is convenient to move, stable to operate, and does not leave dead ends in work.
Specification
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 1
Metric
model
C90T
FCP 200
type
single-direction vibratory plates
reversible vibratory plates
tamping depth
30 cm
30 cm
power type
gasoline/diesel
gasoline/diesel
vibration intensity
15kn
15kn
vibration frequency
2800-5500vpn
5500vpn
gradeability
<25°
<25°
walking speed
15-30 m/min
15-30 m/min
working area
500*520 mm
370*690 mm
weight
90 kg
126 kg
size
1050*500*520 mm
1050*370*690 mm
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 2
Product details
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 3
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 4
Product Advantages 1. Foldable handle design and walking wheel are convenient for transportation. 2. Wear-resistant bottom plate: prolong service life, open design reduces dirty buildings. 3. Heavy shock absorber reduces vibration of upper deck. 4. Excellent quality, low fuel consumption, simple operation and quick construction.
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 5
Packaging & Delivery
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 6
We adopt wooden and iron box to pack machines, better guarantee the safety and quality of products.And we adopt multiple port, multiple exit point. Such as Shanghai, Qingdao, Guangdong and other regions. Product transportation will be faster and more convenient.
Company Profile
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 7
Henan Be-focus Mechanical Equipment Co.,Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system. Henan Be-focus Mechanical Equipment Co.,Ltd was established in the nineties of twenty century and is one of the earliest professional manufacturers in the field of construction machinery In the spirit of professionalism and excellence,we have gradually developed into a large factory with a history of 30 years. The equipment we provid includes steel bar bending machine,steel bar cutting machine steel bar straightening machine concrete laser screed,concrete cutting machinepower plastering machinerollerconcrete screedconcrete mixer and so on. Has more than 100 engineering and technical experience. Construction machinery we can meet your different orders. In addition, our professional R &:D team will provide you with the most convenient service, Since your order, we can provide the best products and service for you.
Customer Photos
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 8
Professional Grade C90T Plate Compactor with 5.5L Fuel Tank and 150 kg Capacity 9
FAQ
1. Who are we? We are based in Henan, China, start from 2005,sell to Domestic Market(40.00%),North America(15.00%),Southeast Asia(10.00%),Africa(10.00%),South America(5.00%),Oceania(5.00%),Western Europe(5.00%),Eastern Europe(3.00%),Mid East(2.00%),Eastern Asia(00.00%),Central America(00.00%),Northern Europe(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 21-50 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.What can you buy from us?
Concrete Mixer,Concrete Pump,Concrete Road Paver,Steel Bar Straightening and Cutting Machine,Steel Bar Bending Machine
4. Why should you buy from us not from other suppliers?
Henan Tatooine Machinery Manufacturing Co., Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system.
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES； Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF; Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow; Language:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian, Korean,Hindi,Italian
