High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings

High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings

Large Image :  High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings

Product Details:
Place of Origin: Henan, China
Brand Name: BE-Focus
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $1,030.00/sets >=1 sets
Contact Now

High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings

Description
Features: Small Size,high Construction Efficiency Application: Buildings, Construction
Condition: New Production Capacity: 2 Modular House Per Day
Warranty: 1 Year Dimension(L*W*H): 1.52*0.68*0.95
Power: 4kw Voltage: 380V, 380V
Applicable Industries: Building Material Shops Weight (KG): 150
Showroom Location: None Video Outgoing-inspection: Provided
Machinery Test Report: Not Available Marketing Type: Ordinary Product
Warranty Of Core Components: 1 Year Core Components: Motor, Pump
UNIQUE SELLING POINT: Low Maintenance Cost Product Name: Mortar Spraying Machine
Motor Power: 4kw Unit Weight: 150kg
Type: Ordinary Product Port: QingDao/ShangHai/TianJin/Dalian/Shenzhen

Products Description
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 0
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 1
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 2
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 3
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 4

Product parameters
Product model
311 type（380v）
511 type (380v)
711 type (380v)
Jifeng06 (380v)
Operating Weight
150kg
300kg
350kg
500kg
Motor power
4kw
7.5kw
9kw
9/11kw
Air pump power
2.2kw
2.3kw
1.5*2kw
1.5*2kw
Overall size
1.52*0.68*0.95m
1.7*0.68*1.1m
1.93*0.68*0.8m
2.1*0.7*1.2m
Vertical height
12m
18m
25m
50m
Horizontal distance
20m
30m
40m
100m
Through particles
4mm
6mm
6mm
6mm
Inner wall of tube
32mm
32mm
38mm
38mm
Standard configuration
10m conveying pipe, one spray gun and four nozzles
10m conveying pipe, one spray gun and four nozzles
20 m conveying pipe, one spray gun, four nozzles, vibrating screen * 1 set
40m conveying pipe, one spray gun, four nozzles, vibrating screen * 1 set


Product application


Products applicable to painting: interior and exterior walls of buildings, high-speed Embankment slope protection, etc 1.Adjust the flow to give full play to the spraying effect. 2.High construction efficiency and good quality. 3.Small size, easy to carry, low cost of accessories and simple maintenance.
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 5
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 6


Model division
Cheap Price Mortar Spray Machine For Rubber Granules Wet Pouring Athletic Track Surface Spray Coating
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 7

1.The mortar spraying machine can be used not only for spraying, but also for pouring mortar. In addition, the mortar spraying machine is commonly known as the fast mortar spraying machine because of its high efficiency of spraying speed.
2.It can also be used to spray putty powder, refractory materials, latex paint, waterproof materials, and can also be called a multi-function spraying machine, but different raw materials need to use different machines.
Our Advantages
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 8
1. Basically, there is no ash on the ground, which saves water and materials, and can reduce costs by more than 20%.
2. Easy to operate, no scaffolding required. No mobile devices, no patching.
3. Quick freezing, high efficiency, and low labor intensity. A 3II spraying machine can easily spray 150 ㎡ per hour.
4. One machine with multiple functions, capable of spraying mortar and fireproof coating. Refractory
5. The mortar compactness far exceeds the national standards. It avoids troubles and losses caused by quality, construction period, labor price, and other issues.
Pruduct Show
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 9
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 10
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 11
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 12

Attention

This product is equipped with wearing parts that can be used for one year.Vulnerable parts are of good quality, but they need to be purchased later
Why Choose Us
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 13
Henan Be Focus Mechanical Equipment Co., Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system. Henan Be Focus Mechanical Equipment Co., Ltd.was established in the nineties of twenty century and is one of the earliest professional manufacturers in the field of construction machinery In the spirit of professionalism and excellence,we have gradually developed into a large factory with a history of 30 years. The equipment we provid includes steel bar bending machine,steel bar cutting machine steel bar straightening machine concrete laser screed,concrete cutting machinepower plastering machinerollerconcrete screedconcrete mixer and so on. Has more than 100 engineering and technical experience. Construction machinery we can meet your different orders. In addition, our professional R &:D team will provide you with the most convenient service, Since your order, we can provide the best products and service for you.
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 14
Main products
Hydraulic I-beam cold bending machine, grid arch splay moldin machine, combined hydraulic punching and shearing machine ,hoisting dry spraying unit, small prefabricated component production line, grouting pump, mixing bucket, etc Product.Widely used in tunnels, bridges, mines, railways, highways, subways, water conservancy, municipal

Company culture
All employees of the company adhere to the principle that credibility is life, quality is survival, and customers are parents The principle is to gain trust by quality, extract value by brand, create differences by creating, and serve To win the competition is your reliable and long-term partner.
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 15

Production Capacity
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 16
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 17
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 18
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 19
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 20
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 21

The company cooperates with all major engineering projects

R&D capability
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 13
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 23
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 24
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 25
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 26
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 27

Packing
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 28

Factory inspection report
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 29
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 30
High Pressure Cement Mortar Spraying Shotcrete Machine for Large Scale Buildings 31


FAQ

Q1.What are your terms of payment?
A: T/T 30% is the deposit, and 70% before delivery. Before you pay the balance, we will show you the photos of the products and packaging.
Q2. What are your delivery terms?
Answer: EXW, FOB, CFR, CIF.
Q3. How about your delivery time? A: Generally, it takes 7-10 working days after receiving your advance payment. The specific delivery time depends on the item and quantity of your order.
Q4. What is the warranty of our machine?
Answer: Our host enjoys a one-year warranty(except hammer), during which all Damaged parts can be replaced with new ones. We provide machine installation and operation video.
Q5. What are your packing conditions?
Answer: LCL goods generally use standard export wooden cases, and the full case goods are fixed. Q6. Do you test all goods before delivery? Ans.: Yes, we conducted 100% tests before delivery. We will attach the inspection report of each machine. Q7. Do you give priority to providing vulnerable parts to trading customers? Ans.: Yes, we have the records of your customers and are more willing to provide them with accessories. Q8: How do you maintain a long-term good relationship with our business? Ans.: 1. We maintain good quality and competitive prices to ensure the interests of our customers; 2. We respect every customer and treat them as friends, no matter where they come from We all sincerely do business and make friends.
Q9. Do you have a certificate for your machine? Ans.: All our products have CE and ISO9001 certificates.
