10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine

10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine

Large Image :  10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine

Product Details:
Place of Origin: Henan, China
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $2,750.00/sets 9-9 sets
Packaging Details: Standard export wooden box packaging
Supply Ability: 100 Set/Sets per Month
Contact Now

10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine

Description
Applicable Industries: Construction Works  Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: Engine, Motor Condition: New
Max Aggregate Size: 20mm Hose Inner Diameter: 51 Mm
Air Consumption: 10-15m3/min Dimension(L*W*H): 2.2*0.9*1.2m
Weight: 900 Kg Warranty: 1 Year
UNIQUE SELLING POINT: High Operating Efficiency Port: Tianjin Port, Qingdao Port, Shanghai Port And Lianyungang Port

Production Show
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 0
Dry concrete spraying equipment is the most ideal equipment for concrete bolt spraying construction, wet spraying, and wet spraying. It is widely used in the construction of anchor and shotcrete support for tunnels, culverts, and underground projects. The uniquely manufactured rubber bushing block on the hydrocyclone facilitates the delivery of the mixture. Stable performance, convenient maintenance, energy saving, long service life, environmental protection, and improved coating quality.
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 1
Model
GSP-6
GSP-7
Production capacity
6m3/h
7m3/h
working pressure
0.4-0.6Mpa
0.6-0.8Mpa
Air consumption
10-15m3/min
10-15m³/min
Motor power
5.5KW
7.5KW
Woltage
380V
380V
transmission distance
50m
50m
Transmission height
20M
20M
Loading height
1.25m
1.25m
Aggregate particle size
20mm
20mm
Outlet diameter
51mm
57mm
Weight
900kg
900kg
 Water cement ratio
≤ 0.4-0.45
≤0.4-0.45
Material ratio
1:3-5
1:3-5
Size
1.9 * 0.9 * 1.2m
2.2*0.9*1.2m
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 2
Model
PZ-6
PZ-7
throughput
6m3/h
7m3/h
working pressure
0.2Mpa-0.4Mpa
0.2Mpa-0.4Mpa
Air consumption
8-10m3/min
8-10m3/min
Motor power
5.5KW
7.5KW
Woltage
380V
380V
transmission distance
200M
200M
Transmission height
20M
20M
Maximum aggregate size
20mm
20mm
Outlet diameter
51mm
57mm
Weight
600KG
850KG
size
1520*900*1200mm
1600*900*1200mm
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 3
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 4
Product details
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 5
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 6
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 7
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 8
Product packaging
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 9
Company Profile
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 10
10-15m3/min Air Consumption Wet Mixed Sand Cement Mortar Pump Plaster Spraying Machine 11
FAQ
1. Q: Are you trading company or manufacturer? A: We are original equipment manufacturer. 2. Q: How long is your delivery time? A: It is according to the model and quantity. Generally it is 3-5 days if the machines are in stock. It will be 15-30 days if you want to customize the machines. 3. Q: Do you provide samples? Is it free or extra? A: Yes, we could offer you the sample machine. But it's not free. You need to pay for the sample and the cost of freight. 4. Q: What is your terms of payment? A: We accept T/T, Alibaba Escrow etc.
