Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M

Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M

Large Image :  Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M

Product Details:
Place of Origin: Henan, China
Brand Name: BE-Focus
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $23,999.00/sets 1-9 sets
Contact Now

Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M

Description
Applicable Industries: Building Material Shops, Manufacturing Plant, Construction Works , Energy & Mining Showroom Location: None
Condition: New Power Type: Electric
Weight: 5790 Kg Dimension(L*W*H): 6250*2100*2200
Warranty: 1 Year UNIQUE SELLING POINT: Low Noise Cab
Max. Vertical Conveying Distance: 180M Max. Horizontal Conveying Distance: 600M
Productivity: 65m³/H Machinery Test Report: Not Available
Video Outgoing-inspection: Provided Marketing Type: Ordinary Product
Warranty Of Core Components: 1 Year Core Components: Motor, Pump
Outlet Pressure: 13Mpa Rated Power: 90KW
Hopper Volume: 0.7m³ Port: QingDao/ShangHai/TianJin/Dalian/Shenzhen

Concrete haulage pump

Tunnel, bridge, construction site, mine, subway, tunnel grouting, etc
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 0
Product Paramenters
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 1
Towed type vehicle pump YL60S technical parameters
Project name
Parameter
Units
Theoretical transfer pressure of concrete(low/high pressure)
8/13
Mpa
Theoretical concrete throughput(low/high pressure)
65/40
m³/h
Rated engine/motor power
90/1480
kw/rpm
Conveying cylinder diameter X stroke
φ200X1400
mmXmm
Hopper volume X loading height
0.7X1320
m³ X mm
Overall dimensions (length X width Xheight)
6250X2100X2200
mmXmmXmm
Total mass
5790
kg
Maximum aggregate size
50/40
mm
Conveying pipe diameter
φ150/ φ125
mm
Type
s-valve
/
Concrete collapse degree
100~230
mm
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 2

High speed and high efficiency

The equipment adopts hydraulic feeding mode, compared with the traditional manual operation, the work efficiency is improved several times, save many processes, save time and cost

Save cost and labor

Compared with the traditional operation mode, the equipment does not need to increase the excess manpower and material resources, can greatly reduce the staffing, greatly reduce the investment of capital cost
Usage scenario
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 3

Tunnel support
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 4

Foundation pit
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 5

Slope netting
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 6


Bridge net laying
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 7
Product advantage
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 8
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 9
Copper motor
Large copper motor,strong power, long service life
Operating system
Simple operation interface, no on-site training, video guidance can be
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 10
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 11
Energy storage system
An accumulator that stores excess pressure and releases it when needed.
Hopper
Storage concrete, ensure pumping mechanism working normal suction, continuous pumping
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 12
Detail description
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 13
Conveying pipe diameter
Φ150/Φ125 Two pipe diameters are available
Aggregate size
support transport 50mm/40mm two sizes of aggregate
Joint clamp
When connected with the conveyor pipe, a joint clamp is required
Pruduct Show
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 14
Recommend Products
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 15
Why Choose Us
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 16
Henan Be Focus Mechanical Equipment Co., Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system. Henan Be Focus Mechanical Equipment Co., Ltd.was established in the nineties of twenty century and is one of the earliest professional manufacturers in the field of construction machinery In the spirit of professionalism and excellence,we have gradually developed into a large factory with a history of 30 years. The equipment we provid includes steel bar bending machine,steel bar cutting machine steel bar straightening machine concrete laser screed,concrete cutting machinepower plastering machinerollerconcrete screedconcrete mixer and so on. Has more than 100 engineering and technical experience. Construction machinery we can meet your different orders. In addition, our professional R &:D team will provide you with the most convenient service, Since your order, we can provide the best products and service for you.
Production Capacity
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 17
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 18
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 19
The company cooperates with all major engineering projects
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 20
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 21
Packing
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 22
Factory inspection report
Concrete Truck Mounted Line Pump 38x-5rz/100 for Max. vertical conveying distance 180M 23
FAQ
Q1.What are your terms of payment? A: T/T 30% is the deposit, and 70% before delivery. Before you pay the balance, we will show you the photos of the products and packaging. Q2. What are your delivery terms? Answer: EXW, FOB, CFR, CIF. Q3. How about your delivery time? A: Generally, it takes 7-10 working days after receiving your advance payment. The specific delivery time depends on the item and quantity of your order. Q4. What is the warranty of our machine? Answer: Our host enjoys a one-year warranty(except hammer), during which all Damaged parts can be replaced with new ones. We provide machine installation and operation video. Q5. What are your packing conditions? Answer: LCL goods generally use standard export wooden cases, and the full case goods are fixed. Q6. Do you test all goods before delivery? Ans.: Yes, we conducted 100% tests before delivery. We will attach the inspection report of each machine. Q7. Do you give priority to providing vulnerable parts to trading customers? Ans.: Yes, we have the records of your customers and are more willing to provide them with accessories. Q8: How do you maintain a long-term good relationship with our business? Ans.: 1. We maintain good quality and competitive prices to ensure the interests of our customers; 2. We respect every customer and treat them as friends, no matter where they come from We all sincerely do business and make friends. Q9. Do you have a certificate for your machine? Ans.: All our products have CE and ISO9001 certificates.
