Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M

Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M

Large Image :  Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M

Product Details:
Place of Origin: Henan, China
Brand Name: BE-Focus
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $1,710.00/units >=1 units
Contact Now

Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M

Description
Applicable Industries: Building Material Shops, Construction Works , Energy & Mining Showroom Location: None
Condition: New Power Type: Electric
Weight: 560 Kg Warranty: 1 Year
UNIQUE SELLING POINT: High Load Moment Max. Vertical Conveying Distance: 60M
Max. Horizontal Conveying Distance: 120M Productivity: 22M³/H
Machinery Test Report: Not Available Video Outgoing-inspection: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: Motor, Bearing, Pump Port: QingDao/ShangHai/TianJin/Dalian/Shenzhen

Products Description
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 0
Mainly used for tunnel excavation and maintenance, road, bridge, dam, mine construction and high-rise building foundation treatment engineering and all kinds of grouting construction engineering, dam foundation curtain grouting (greater than 5Mpa), consolidation grouting and high slope, long distance anchoring grouting and large displacement long distance conveying slurry, as well as the need for pressure grouting.
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 1
Product Paramenters
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 2
Model
BW150
Piston stroke
70mm
Cylinder diameter
φ70mm
Pump speed
47-222r/min
Flow capacity
32-150L/min
Pressure
1.8-7Mpa
Input speed
580r/min
lnlet pipe diameter
φ15mm
Drain pipe diameter
φ32mm
Input torque
48Nm
Dynamic force
7.5kw
Overall size
1840*795*95mm
Weight
560kg
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 3
Model
BW250
Piston stroke
100mm
Cylinder diameter
φ80mm
Pump speed
42-200r/min
Flow capacity
52-250L/min
Pressure
2.5-6Mpa
Input speed
500r/min
lnlet pipe diameter
φ76mm
Drain pipe diameter
φ32mm
Input torque
48Nm
Dynamic force
15kw
Overall size
1700995*650mm
Weight
760kg
Product details
Bw Series High-efficiency Mud Pump Mine Electric Piston Type Mud Pump
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 4
Usage scenario
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 5
Pruduct Show
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 6
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 7
Product packaging
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 8
Recommend Products
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 9
Company Information
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 10
Henan Be Focus Mechanical Equipment Co., Ltd. is a professional production and processing company for steel machinery, concrete mixers, road machinery, batching machines, etc. It has a complete and scientific quality management system. Henan Be Focus Mechanical Equipment Co., Ltd.was established in the nineties of twenty century and is one of the earliest professional manufacturers in the field of construction machinery In the spirit of professionalism and excellence,we have gradually developed into a large factory with a history of 30 years. The equipment we provid includes steel bar bending machine,steel bar cutting machine steel bar straightening machine concrete laser screed,concrete cutting machinepower plastering machinerollerconcrete screedconcrete mixer and so on. Has more than 100 engineering and technical experience. Construction machinery we can meet your different orders. In addition, our professional R &:D team will provide you with the most convenient service, Since your order, we can provide the best products and service for you.
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 11
Bw Series Mud Pump for Mine Electric Piston Type Max. vertical conveying distance 60M 12
FAQ
Good Quality: We are a Large enterprises with more than 24 years history. that we focus on production and development, so we are professional. We have strict quality control system. Good reputation in the market.
Fast & Cheap Delivery: We have considerable experience in manufacturing drilling rig and have a good reputation. We can offer competitive price and durable products.

Q1: Do you have after-sales service?
A: Yes. 1. Our sales team will answer your questions within 24 hours (holiday).
2. Technicalsupport will be available at all times. Once the fault caused by the quality of our products is confirmed,afreereplacement will be provided.

Q2: Do you test all items before shipping?
A: Yes, we have passed 100% testing before delivery. We will attach our inspection report to each machine.

Q3: How do you build long-term and good business relationships with us?
A:1. We maintain excellent quality and competitive prices to ensure that our customers benefit;
2. We respect each customer and regard it as a friend, no matter where they come from, we sincerely do business with them and make friends.

Q4: What is your packaging condition?
A: Usually, we use the standard export wooden box for LCL cargo and fix the full container.

Q5: What is your delivery time?
A: The exact delivery time depends on the item and quantity you ordered.
